Specifications
| Measurement range | (0~500N) (Other ranges can be customized) |
| Accuracy grade | Level 1 |
| Test force test range | 0.4% ~ 100%FS |
| Force Accuracy | ±0.3% |
| Indication Precision | Error of indication/indication variability ≤ 0.3% |
| Measurement range | (0~600) mm (under 100mm test length) |
| Test speed error | (5~100)mm/min±0.2mm/min. |
| Clip spacing positioning error | ±0.2mm |
| Moving chuck reset error | ±0.05mm |
| Force resolution | 0.001N |
| Force unit | N, g, kg, Lb, kpa and other units |
| Deformation resolution | ≤0.1mm |
| fixture | Three-point bending fixture (width 50mm, lower support 180mm) |
| clip spacing | The test length is (1~ 600) [can be customized] |
| stretching speed | (1~ 550) mm/min stepless speed change |
| return speed | 150mm/min stepless speed change [ (1~ 550) mm/min adjustable] |
| Transmission screw | Adopting Taiwan, China single-column structure precision ball screw |
| shell | Made of aluminum alloy |
| motor | Stepping motor, 0~500mm/min stepless speed change |
| Human Machine Interface | 5.0In touch screen control |
| printout | Built-in modular integrated thermal printer |
| communication output | Built-in R232 interface, connected to computer software upgrade version (optional) |
| exterior size | 550*550*1100mm |
| Weight | About75kg |
| Power supply Voltage | 220v、50Hz |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 540 days
