Specifications
| Force range | 50~30000N |
| Measurement size | (600 * 400 * 600) mm/(800 * 600 * 800) mm; (1000 * 800 * 1000) mm/(1200 * 1000 * 1200) mm; (1200 * 1200 * 1200) mm/(1500 * 1500 * 1500) mm; other sizes can be customized according to customer requirements |
| test function | Determination of compressire strength, stacking strength, constant value strength, compression displacement |
| Force Accuracy | +/- 1% or less |
| Sensing deformation error | ≤±1mm |
| Sensors Analytical Accuracy | 0.3% |
| Plate parallelism | ≤1mm |
| Deformation Accuracy | ≤0.1mm |
| Pressurization speed | 5~ 300mm/min stepless adjustable |
| Unit switch | N、kgf、Lbf |
| printout | modular integrated thermal printer |
| Computer control | Computer-specific analysis software, Linear dispersion detail analysis, with dedicated programmable file management analysis report, A4 printing (optional) |
| Safety Devices | 1. Stroke protection: high is the Upper/Lower limit protection switch to prevent exceeding the preset stroke; 2. Force protection: the system can set the force value to prevent exceeding the sensor calibration value; 3. Emergency stop device: This high is equipped with an emergency stop switch, which can handle emergencies; |
| Operating Environment | Temperature (20 +/- 10 ℃), Humidity < 85% |
| Power supply Voltage | 220V / 50Hz,: 400W ~ 2000W |
| Dimensions | Different Dimensions |
| Weight | Different sizes and Weights |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 540 days
