Specifications
| Measurement range | 50~1400kpa |
| Clamping Force | 400~1200Kpa |
| Oil delivery speed | 95±5mL/min |
| Resolution | 0.1kpa |
| Error of indication | ±0.5%F.S |
| System sealing | At the upper limit of measurement, 1 minute pressure drop < 10% Pmax |
| Upper clamp ring aperture | Φ(30.5±0.1)mm |
| Communication interface | Configurable Rs232 (optional) |
| unit conversion | Kg/cm2、kpa、lbf/in2 |
| printout | modular integrated thermal printer |
| Power supply Voltage | 220V±10% 50Hz |
| Lower clamp ring aperture | Φ(33.1±0.1)mm |
Packing list
Host X1, power cord X1, manual X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/33192/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
