Specifications
| Measurement range | 0~20mm |
| Resolution | 0.001mm |
| Error of indication | ±0.0025mm/±0.5% |
| Measurement plane parallelism | ≤0.001mm |
| Contact area | 2±0.05cm²、10±0.2cm² |
| Contact Pressure | 0.5~500kPa、0.1~100kPa |
| Measurement speed | ≤3mm/s |
| Dimensions | 330*340*350mm |
| Weight | About 20kg |
Packing list
After-sales instructions
None
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/33207/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
