Specifications
| Maximum test force | 20kN (2 tons) |
| Force resolution | 1N |
| Speed adjustment range | 1mm/min~80mm/min |
| Plate size | 1000*1000mm |
| Working Travel | 1000mm |
| Standard pressurization speed | 10 mm/min |
| Pressurization speed | 2mm/min |
| Power supply Voltage | AC220V 50HZ |
| Dimensions | About 1360 * 1000 * 1600mm |
| Weight | Approx. 500kg |
Packing list
After-sales instructions
None
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/33251/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
