Specifications
| Capacity selection | 0~30KG |
| Accuracy grade | Level 0.5 |
| Maximum load | 30KG |
| Measurement range | 0.02/100-100% |
| Test force resolution | Maximum load 250,000 code; inside and outside are not divided, and the whole resolution remains unchanged |
| Effective test width | 100mm |
| Efficient stretching of space | 650mm |
| Test speed range | 0.01~500mm/min |
| Speed Accuracy | ±0.5% |
| Measurement Accuracy | +/- 0.5% of the indication |
| Acquisition sensing method | High-Precision Sensors |
| Control system | Stepper motor and stepper drive control |
| Test bench lifting device | Computer digital control/manual jog control |
| Safety protection device | Software automatic diagnosis, electronic limit |
| re-test | Manual can return to the initial position of the test at the highest speed, and automatic can return automatically after the test is over |
| Fixture configuration | Customized according to user product sample requirements |
| motor | 400W |
| Weight | About 55kg |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/33265/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
