Specifications
| Measurement range | (10~1000) mN, of which the standard pendulum and light pendulum are standard configurations, and the lightest pendulum is specially customized according to user requirements |
| Measurement range | Standard pendulum: (10~1000) mN, Graduation 10mN |
| pendulum | (10~500) mN, Graduation 5mN |
| lightest pendulum | (10~200) mN, Graduation 2mN |
| Error of indication | +/- 1% within the range of 20% to 80% of the upper limit, +/- 0.5% FS outside the range |
| Indication Repeatability Error | ≤ 1% within the range of 20% to 80% of the upper limit value, ≤ 0.5% FS outside the range |
| Tear arm | 104±1mm |
| tearing initial angle | 27.5±0.5° |
| tear distance | 43±0.5mm |
| Paper surface size | 25*15mm |
| Distance between clamps | 2.8±0.3mm |
Packing list
After-sales instructions
None
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/33356/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
