Specifications
| Force range | 50-10000N (Miscellaneous range can be customized) |
| Error of indication | ±1% |
| Measurement size | 600Mm × 800mm × 800mm (maximum length, width and height of the sample) 800mm × 1000mm × 1000mm (maximum length, width and height of the sample) 1000mm × 1200mm × 1200mm (maximum length, width and height of the sample, Miscellaneous size can be customized) |
| Force resolution | 0.1N |
| Pressurization speed | 10±3mm/min |
| deformation error | ≤±1mm |
| Plate parallelism | ≤1mm |
| Unit switch | N、kgf、Lbf |
| Environmental temperature | 15℃-50℃ |
| Relative Humidity | Up to 70% RH |
| Power supply Voltage | 220V,50Hz |
Packing list
After-sales instructions
None
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/33381/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
