Specifications
| induction method | pressure converter |
| print data | The test value has average value, time, date and other data |
| Instruction method | Digital A/D value progress rate 40 times/S, Test Accuracy is high |
| Measurement range | ≤6000kPa |
| Oil delivery speed | 170±10mL/min |
| Clamping Force | >690Kpa |
| motor | 1/4HP |
| Dimensions | 500*430*500mm |
| Weight | 65Kg |
| air source pressure | 0.5MPa-0.7MPa (gas source customer-provided) |
| Environmental temperature | 15-50℃ |
| Relative Humidity | Up to 70% RH |
| Power supply Voltage | 220V50HZ |
Packing list
After-sales instructions
None
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/33442/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
