Specifications
| Measurement range | 0~5mm |
| Measurement Accuracy | 0.001mm |
| Error of indication | ±0.05% |
| Contact area | 1000±20mm² |
| Contact Pressure | 2±0.1kpa |
| Measurement plane parallelism | ≤0.035mm |
| Operating Environment | Temperature (20 +/- 10) ℃, Humidity < 85% |
| Dimensions | 100*150*200mm |
| Weight | 2kg |
Packing list
After-sales instructions
None
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/33448/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
