Specifications
| load cell | Level 0.5 high-precision Power Sensors |
| Maximum test force | 5000 kg |
| Accuracy level | Level 1 |
| Test force test range | 0.4%~100%FS |
| Force Accuracy | +/- 1% or less |
| Analysis | 1/200000 |
| force magnification | full automatic |
| Displacement error of indication | +/- 1% of the indication |
| Displacement resolution | 0.05mm |
| Control mode | Microcomputer, touch screen optional |
| Transmission mode | AC variable frequency motor motor |
| Motor function | 2.0Kw |
| Test speed range | 10~300min/mm |
| Speed Accuracy | +/- 1% of the indication |
| Test space | 1000 * 1000 * 1000 mm, 1200 * 1200 * 1200 mm, 1500 * 1500 * 1500mm optional, can also be customized according to customer requirements |
| display system | Special software for material testing machine developed by PK-2000 based on XP leveling |
| Automatic shutdown device | 1. Upper and lower limit travel protection device 2. Maximum Capacity overload protection 3. Leakage protection |
| Volume | 150×100×200cm |
| Weight | About 1000kg |
| Power supply Voltage | AC~220V 50Hz |
