Specifications
| Specimen size | 38 * 70mm (standard size) |
| Actual measurement size | 38 * 50mm (standard) |
| bending length | 60mm、50mm、40mm、30mm、25mm、20mm、15mm、10mm、5mm |
| span Accuracy | ±0.1mm |
| Measuring range | 0 ~ 10000mN |
| Sensors | Sensing Accuracy ± 0.1% |
| resolution | 0.01mN |
| Bending angle | Adjustable from 1 to 92℃ |
| Angle Accuracy | ±0.1 |
| Angle measurement | A single test can measure 3 different angles at the same time, and 1-90 ° can be set arbitrarily. |
| Angular velocity control | 0.5~ 50 °/sec (adjustable), three test angles and duration are independently adjustable |
| Film thickness measurement | Film thickness in (0.01~ 5.0) mm paper and other composite materials |
| Bending time | Choose different bending times based on material elasticity |
| Specimen holder | Manual fixture operation, automatic reset after test completion |
| Display | 7Inch touch screen operation interface, visual menu operation. |
| Clamping method | Unlimited blessing, continuous clamping without damage |
| signal output | Standard computer signal output, link to computer, computer operating platform, can realize document editing (optional) |
| Self-calibrating | Equipment can be self-calibrated, standard calibrating tools |
| printout | Modular integrated thermal printer |
Packing list
complete-built unit X1, manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. The quality warranty period of the whole machine is one year, and free maintenance is provided for product quality problems during the warranty period (except for man-made damage).
2. Provide lifelong technical services for products outside the warranty period. If repairs are required, only the material fee will be charged, and the maintenance fee will be waived for life.
3. Respond within 3 hours after accepting the service request, and put forward handling opinions and solutions within 24 hours.
4. The returned product will be processed within 5 working days after receipt, and the user will be notified of the processing situation
