Specifications
| power resolution | 1/100000 |
| Data analysis sampling | Sampling Frequency 400 times/second |
| Force Precision | ±0.1%(20~100％FS) |
| Force Precision | ≤±0.5% |
| Displacement resolution | ≤0.1mm |
| Sample holding method | Pneumatic automatic clamping |
| clamping pressure | 0.2 - 0.7Mpa (adjustable) |
| Specimen size | 1-25mm |
| Force range | 0.4~100%FS |
| Measurement range of elongation | 45-260mm |
| Test speed Accuracy | （1~10）mm/min：±0.1mm/min |
| clip spacing | The test length is arbitrarily selected in the range of (1 to 250) mm |
| stretching speed | 1~ 500mm/min stepless speed change |
| return speed | 100mm/min |
| Force range | 3~ 30N (for household paper), 6~ 500N for cultural paper, Encasement paper, special paper, paper-based composites, etc |
| Sensing system protection | Rapid sensor protection device PROTEC SYSTEM |
| Transmission screw | Adopting Taiwan, China single-column structure precision ball screw |
| Human Machine Interface | 7.0In touch screen operation platform, detection status with Linear dispersion diagram display.) |
| printout | modular integrated thermal printer |
| Dimensions | 650*500*400mm |
| Weight | About 45kg |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/33477/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
