Specifications
| Measurement range | 0~99999 times |
| folding angle | Material yield bending angle is steplessly adjustable from 0 ° to 142 ° |
| folding speed | The bending speed is adjustable from 10 times/min to 2000 times/min |
| Spring tension | 4.91~ 14.72N, plus a force of 9.81N, the spring compresses at least 17mm. |
| Test tension configuration | Adopting imported tension configuration, the tension coefficient is twice higher than that of China brand Stability. |
| Folding chuck | The tension change caused by swirl/spin eccentricity is not more than 0.343N. |
| The width of the folding head is | 19±1mm |
| crease radius | 0.38±0.02mm |
| Specimen length | ≥140mm |
| Crease temperature change | ≤1℃ ，AFTER 4H |
| Collet distance | 9.5mm |
| Lower clamp clamping method | Cylinder knurled knob for easier clamping |
| The distance between the cracks of the folding mouth | 0.25Mm/0.5mm/0.75mm/1.00mm (according to requirements) |
| Display | 5.in LCD display, real-time display of test data |
| printout | modular integrated thermal printer |
| Operating Environment | Temperature (0~35) ℃, Humidity < 85% |
| Power supply Voltage | AC220V，50Hz |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/33479/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
