Specifications
| Force range | 5~3000N |
| Accuracy | ≤±0.5% |
| Force range | 0.4%~100%FS |
| Displacement speed | 100 r/min |
| Power Accuracy | Within ± 1% |
| Force Resolution | 0.1N |
| Test speed benefit ratio | 1:05 |
| Deceleration ratio | 1:40 |
| deformation resolution | ≤0.1mm |
| Pressurization speed | 12.5±1mm/min |
| Upper and lower platen parallelism | ≤0.05mm |
| Operating System | Adopt American AD converter to improve detection linearity |
| Human Machine Interface | Touch screen control, Chinese and English switching |
| printout | Modular integrated thermal printer |
| Metrology authentication | Sensors are calibrated according to the standard calibrating box of South China Measurement Center, and can withstand metrology authentication from any national or third-party testing agency at any time |
| Electromagnetic wave anti-interference system | The integrated circuit board is installed with a professional terminal machine to isolate the electronic module and cut off the influence of electromagnetic waves on the circuit system |
| Dimensions | 40*37*56cm |
| Weight | 60kg |
Packing list
complete-built unit X1, manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. The quality warranty period of the whole machine is one year, and free maintenance is provided for product quality problems during the warranty period (except for man-made damage).
2. Provide lifelong technical services for products outside the warranty period. If repairs are required, only the material fee will be charged, and the maintenance fee will be waived for life.
3. Respond within 3 hours after accepting the service request, and put forward handling opinions and solutions within 24 hours.
4. The returned product will be processed within 5 working days after receipt, and the user will be notified of the processing situation
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/33485/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
