Specifications
| Measurement range | A file (0~1000) ml/min, B file (0~5000) ml/min, C file (0~10000) ml/min, D file (0~100000) ml/min (B, C, D file are optional gears) |
| test area | The standard specimen test is 10 +/- 0.2 cm ², and the specimen needs to be larger than this size. |
| Differential pressure in test area | The standard test pressure difference is 1 +/- 0.01kPa, and other pressure differences can be customized for special materials upon request. |
| Measurement head | 304 #stainless steel Porosity measurement fixture, aging resistant silicone sealing. |
| Measurement Accuracy | ±1ml(<100ml)；±5ml(>100ml) |
| Measuringflask Shelf material | Resistant corrosion material, Saigang, long time to eliminate corrosion problems after use |
| Barometer bracket | Anti-corrosion structure treated with aluminum alloy anode |
| Catheter material | Adopt silicone catheter to eliminate aging problems caused by long-term use |
| Valve material | Use pure copper valve to prevent rusting valve phenomenon |
| Inner diameter of clamp ring | 35.68±0.05mm |
| Coaxiality of Upper/Lower clamp ring center hole | <0.05mm |
| Environmental conditions temperature | (0~35) ℃, Humidity < 85% |
| Dimension | 400*300*1200mm |
| Weight | About 38kg |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. The quality warranty period of the whole machine is one year, and free maintenance is provided for product quality problems during the warranty period (except for man-made damage).
2. Provide lifelong technical services for products outside the warranty period. If repairs are required, only the material fee will be charged, and the maintenance fee will be waived for life.
3. Respond within 3 hours after accepting the service request, and put forward handling opinions and solutions within 24 hours.
4. The returned product will be processed within 5 working days after receipt, and the user will be notified of the processing situation
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/33487/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
