Specifications
| Measurement range | 1~125mm |
| Probe Frequency | 5MHz dual element |
| Probe style | Split probe (UTG C (corrosion)) |
| Probe diameter | F13mm |
| Measurement error | ±0.03mm |
| Display resolution | 0.01mm |
| unit system | mm/inch |
| Calibration method | One point calibrated, two point calibrated |
| Measurement mode | single echo |
| Storage Capacity | 250 pieces |
| Statistical function | Average, standard deviation, Min/Max Film thickness and number of readings |
| Standards | ASTM E797 |
| Display | LCD |
| Operating language | Chinese, English |
| Interface | USB |
| Application software | Yes. |
| Protection level | Protection against solvents, acids, oils, water and dust |
| Power | 3 * 7 battery |
| Host size | 146*61*28mm |
| Weight | 140G (excluding batteries) |
Packing list
Host x1, probe x1, probe protective cover x1, lens protective cover x1, wristband x1, coupling agent x1, rubber protective cover with waist clip x1, No. 7 battery x3, nylon portable soft bag x1, English manual x1, certificate x1
After-sales instructions
Warranty days: 365 days
Non-artificially caused product quality problems, the manufacturer will be free of charge during the warranty period, and only the cost of spare parts will be charged outside the warranty period;
1-year warranty for the host and 6-month warranty for the probe, except for other accessories and consumables;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/3349/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
