Specifications
| Indication Precision | Error of indication +/- 1%, indication variability ≤ 1% |
| Measurement range of elongation | (0~130) mm (under the standard test length of 180mm) |
| Test speed error | （5~10）mm/min：±1mm/min、（10~100）mm/min：±5%、（100~500）mm/min：±6% |
| Force Accuracy | +/- 1% or less |
| Clip spacing positioning error | ±0.5mm |
| Moving chuck reset error | ±0.1mm |
| Force resolution | 0.1N |
| Deformation resolution | ≤0.1mm |
| clip spacing | The test length is arbitrarily selected in the range of (1 to 400) mm |
| stretching speed | (6~ 150N) 1~ 500mm/min infinitely variable speed, (6~ 1500) N 1~ 180mm/min infinitely variable speed. |
| return speed | 5~180mm/min |
| Sensing system protection | Rapid sensor protection device PROTEC SYSTEM |
| distance limit | High-precision distance limit switch, external, can be adjusted according to different material requirements |
| Transmission screw | Adopting Taiwan, China single-column structure precision ball screw |
| Human Machine Interface | 7.0In touch screen operation platform, detection status with Linear dispersion diagram display. |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
