Specifications
| Measuring range | 0~4mm |
| Measurement Accuracy | 0.01mm/0.001mm |
| Error of indication | ±0.05% |
| Contact area | 200±5mm² |
| Contact Pressure | 100 ± 5kpa |
| concentricity | 4 point positioning one molding |
| Vertical parallelism control | 52mm vertical and parallel positioning |
| Lateral parallelism control | (R1 + R2) 32mm horizontal parallel positioning |
| Measurement plane parallelism | ≤0.035mm |
| Weight | About 5kg |
| Operating Environment | Temperature (20 ± 10) ℃, humidity < 85% |
Packing list
complete-built unit X1, manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. The quality warranty period of the whole machine is one year, and free maintenance is provided for product quality problems during the warranty period (except for man-made damage).
2. Provide lifelong technical services for products outside the warranty period. If repairs are required, only the material fee will be charged, and the maintenance fee will be waived for life.
3. Respond within 3 hours after accepting the service request, and put forward handling opinions and solutions within 24 hours.
4. The returned product will be processed within 5 working days after receipt, and the user will be notified of the processing situation
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/33500/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
