Specifications
| Measuring range | 0~99999 times |
| folding angle | Material yield bending angle Infinitely adjustable from 0 ° to 142 ° |
| Test tension configuration | With imported tension configuration, the tension coefficient is twice higher than the stability of domestic (CN) brands |
| Folding collet | The tension change caused by swirl/spin eccentricity is not more than 0.343N |
| Folding radius | 0.38±0.02mm |
| Specimen length | ≥140mm |
| Collet distance | 9.5mm |
| The distance between the cracks of the folding mouth | 0.25mm/0.5mm/0.75mm/1.00mm (according to requirements) |
| Human Machine Interface | 5.in LCD display, real-time display of test data |
| printout | Modular integrated thermal printer |
| Operating Environment | Temperature (0~35) ℃, humidity < 85% |
| Power | AC220V，50Hz |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. The quality warranty period of the whole machine is one year, and free maintenance is provided for product quality problems during the warranty period (except for man-made damage).
2. Provide lifelong technical services for products outside the warranty period. If repairs are required, only the material fee will be charged, and the maintenance fee will be waived for life.
3. Respond within 3 hours after accepting the service request, and put forward handling opinions and solutions within 24 hours.
4. The returned product will be processed within 5 working days after receipt, and the user will be notified of the processing situation
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/33502/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
