Specifications
| Measurement range | 2.50~125.00Mm (single echo); 2.50~60.00mm (multiple echoes) |
| Probe Frequency | 5MHz |
| Probe style | Split probe (UTG M (multiple echoes)) |
| Probe diameter | Φ13mm |
| Measurement error | ±0.03mm |
| Display resolution | 0.01mm |
| unit system | mm/inch |
| Calibration method | Two or three point calibrated |
| Measurement mode | Single echo, multiple echo (ability to penetrate paints) |
| Storage Capacity | 100000 Measured values, 1000 groups |
| statistical function | Average, standard deviation, minimum/maximum thickness and number of readings |
| Standards | ASTM E797 |
| Display | Color LCD screen |
| Operating language | Chinese, English |
| Interface | USB |
| Application Software | Yes. |
| Protection level | Protection against solvents, acids, oils, water and dust |
| Power Supply | 3 * 7 battery |
| Host size | 146*61*28mm |
| Weight | 140G (excluding batteries) |
Packing list
host x1, probe x1, probe protective cover x1, lens protective cover x1, wristband x1, coupling agent x1, rubber protective cover with waist clip x1, No. 7 battery x3, nylon portable soft bag x1, English manual x1, certificate x1.
After-sales instructions
Warranty days: 365 days
Non-artificially caused product quality problems, the manufacturer will be free of charge during the warranty period, and only the cost of spare parts will be charged outside the warranty period;
1-year warranty for the host and 6-month warranty for the probe, except for other accessories and consumables;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/3352/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
