Specifications
| Light source | CIE-A、CIE-C、CIE-D65 |
| follow the standard | ASTM D1003/D1044，ISO13468/ISO14782，JIS K 7105，JIS K 7361，JIS K 7136，GB/T 2410-08 |
| Measurement parameters | ASTM and ISO Dual Standard Haze (HAZE), Transmittance (T) |
| Light spectrum Response | CIE Light spectrum function Y/V (λ) |
| optical path structure | 0/d |
| Measurement aperture | 21mm，7mm |
| range | 0-100% |
| Haze resolution | 0.01% |
| Transmittance resolution | 0.01% |
| Haze Repeatability | φ 21mm diameter, within 0.05 (30 standard deviation differences for standard haze films with a test haze of about 40 at intervals of 5s) |
| Repeatability | ≤0.1% |
| Sample size | Thickness ≤ 145mm |
| store data | Mass Storage |
| screen | 7-Inch full-color touchscreen, Android Operating system |
| interface | USB port |
| Power Supply | DC12V |
| Operating temperature | 10~40 ℃, Relative Humidity 80% or less (at 35 ℃), no water condensation |
| Storage temperature | -20 ℃~ 50 ℃, Relative Humidity 80% or less (at 35 ℃), no water condensation |
| Volume | Length X width X height: 310mmX215mmX540mm |
| Standard | PC management software (Haze QC) |
| optional | Measurement fixture, haze standard sheet, 5/10mm custom diameter plate, 40 * 10 Colorimetric dish |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 1095 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/33537/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
