Specifications
| Light source | D65,A,C |
| Measurement parameters | ASTM standard haze (HAZE), transmittance (T) |
| Measurement aperture | 21mm |
| Screen size | 5-Inch full-color LCD screen |
| Haze Repeatability | φ 21mm diameter, within 0.1 (30 standard deviation differences for standard haze films with a test haze of about 40 at intervals of 5s) |
| Repeatability | ≤ 0.1 unit |
| optical path structure | Transmission: 0/D (parallel light illumination, diffuse reflection reception) |
| Integrating sphere size | Φ154mm |
| Lighting source | 400~700Nm Light spectrum LED Light source |
| range | 0-100% |
| Haze resolution | 0.01 unit |
| Transmittance resolution | 0.01 unit |
| Sample size | Open space with no size restrictions |
| store data | 10000 values |
| interface | USB port |
| Power Supply | DC12V |
| Operating temperature | +10 – 40 ℃ (+50 – 104 °F) |
| Storage temperature | 0 – 50 ℃ (+32 – 122 °F) |
| Volume | Length X width X height: 310mmX215mmX540mm |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 1095 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/33538/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
