Specifications
| Range (standard probe: 5P, φ10) | Standard mode range: 0.75-500mm Penetration mode range: 2.5-25mm (coating thickness should be less than 2mm) |
| Display Accuracy | 0.01mm |
| Measurement error | ±(0.5%H+0.05)mm |
| material speed of sound | 1000-9999m/s |
| LCD | 2.3-Inch large color screen display |
| Calibrating function | Instrument calibrated and sound speed calibrated |
| data storage | Each group can store 200 data, a total of 10 groups can store 2000 data |
| Power level display | Yes. |
| Bluetooth | optional |
| Shutdown method | Manual/automatic (automatic shutdown without operation for 5 minutes) |
| Host size | 130mm*70mm*26mm |
| Power | Three (7) alkaline batteries |
| Operating temperature | 0℃-50℃ |
| Operating humidity | 20%RH - 90%RH |
| Weight | 125G (without probe and battery) |
Packing list
Host X1, standard probe (5P, φ 10) X1, calibration shim X1, coupler X1, battery X3 section No. 7, manual X1, certificate X1, ABS instrument bag X1
After-sales instructions
Warranty days: 365 days
【Attention】
1. The manufacturer promises to provide a one-year warranty period for the product for customers in Nanbeichao Mall
2. During the warranty period, the freight sent back and forth by the customer shall be borne by the customer
3. The damage caused by improper use by customers and the damage caused by the logistics process are not covered by the free warranty.
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/33592/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
