Specifications
| Rated Voltage | AC 220V |
| Rated Frequency | 50/60 Hz |
| Input Power | 950W |
| output power | 570W |
| Rated torque | 3.92 N.m |
| Operating Mode | S1 (continuous) |
| Speed range | 1000~14000rpm |
| Speed regulation mode | Promise |
| Rotation speed display | LED |
| Timer | 1~1000min |
| Overload protection function | Yes |
| Rotation speed dynamic detection function | Yes |
| Rotation speed memory function | Yes |
| Approved torque | 38.5 N.cm |
| Rotor maximum linear velocity | 22s/m |
| Work head material | SS 316L stainless steel |
| Work head specification | Φ70 mm |
| Internal stator standard configuration | Square Hole/Round Hole/Oblique Hole |
| External stator standard configuration | Square Hole/Oblique Hole |
| Processing Capacity | 500 ~ 40000mL |
| Max. Processing Viscosity | 8000cp |
| Environmental temperature | ≤40℃ |
| Allowable Relative Humidity | ≤80% |
| Dimensions | 215*310*720mm |
| Machine Weight | 9.6kg |
