Specifications
| Temperature range | RT+~300℃ |
| Measuring method | Hot stage method, visual |
| Temperature Resolution | 0.1℃ |
| Heating rate | Optional continuously between 0.1 and 20 ℃/min |
| Error of indication | ±0.5℃(≤200℃)；±0.7℃(>200℃) |
| Repeatability | ±0.3℃(1.0℃/min) |
| linear Heating rate error | ±10% |
| Data storage | 3000 sets |
| Printer model | RD-TH32-SC (optional) |
| Display mode | 7-Inch color LCD touch screen |
| Interface | RS232/USB |
| Slide thickness | 0.8~1.2mm |
| Slide thickness | 0.17mm |
| magnification | ≥ 40X (depending on the configured Microscope) |
| Power Supply | 220V±22V 50Hz±1Hz |
| Hot mirror table size | 195mm×28mm×85mm |
| Digital display unit size | 290mm×170mm×360mm |
| Net Weight of instrument | 9Kg (without Microscope) |
| XSP-8CA Trinocular Biological Microscope (Set 1) | Electronic eyepiece with 1.30 million pixels |
| XTZ-TV Video Continuous Diploidy Microscope (Set 2) | With Display, continuous zoom |
| 59XC Trinocular Polarizing Microscope (Set 3) | Electronic eyepiece with 1.30 million pixels for polarized viewing |
| 69XCL reflection Polarizing Microscope (Set 4) | Electronic eyepiece with 1.30 million pixels for polarized viewing |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/33668/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
