Specifications
| Lighting method | 8°/d |
| Sensors | Silicon photodiode array |
| Measurement light source | D65,D50,A |
| Measurement time | About 0.5s |
| Measurement caliber | Φ8mm |
| Repeatability | ≤0.06ΔE*ab |
| Operating language | Simplified Chinese, English |
| Interface | USB port |
| Viewing Angle | CIE 10° |
| Lighting source | LED blue excitation |
| Color difference formula | ΔE*ab、ΔL*a*b*、ΔE*C*h*、ΔECIE94、ΔEhunter |
| data storage | 100 standards 20,000 samples |
| Power supply Voltage | High Capacity lithium ion polymer battery |
| display mode | CIEL * a * b * C * h * CIEL * a * b * CIEXYZ CIERGB CIEL * u * v * CIEL * C * h yellowness whiteness colour fastness |
| Operating environment | -10~40 ℃, 0~85% Relative Humidity (no condensation) |
| Dimension | 205*70*100mm |
| Weight | 500g |
| Inter-instrument Agreement | ΔE*ab<0.4 |
| Display | 2.8 inch TFT true color LCD screen |
| Lamp life | More than 1.60 million measurements in 5 years |
| Charging time | About 8 hours~ 100% battery |
| Measurable times after charging | 3000 measurements in 8 hours |
| Shop accessories | φ 8mm extended diameter, can measure concave parts, micro thermal printers, powder test boxes, multi-functional test components |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/33688/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
