RDS 16 #3/8 "Molded Linear Spreader Rod 36.6μm Thin Film wire-wound drawdown Bar
SEImported from the United States, the production process is formed, the wet film thickness is 36.6μm, the diameter is 9.52mm, the Total length is 400mm, the width of the Spreader is 300mm, and the material is stainless steel.
$161.00/piece
PromotionLoading...
Coupon
Model：
16# 3/8"
Similar products
-
RDS 16 #3/8 "Mayer Rods WFT 36.6μm Length 400mm$ 161.00SE -
RDS 16 #1/4 "wire-wound Applicator rod film thickness 36.6μm Wire diameter 0.41mm$ 155.00SE -
RDS 16 #1/2 "Steel Wire Drawdown Rod film thickness 36.6μm Wire diameter 0.41mm$ 179.00SE -
Japan OSP-40/400 formed thread rod WFT 40μm length 400mm$ 172.00SE -
RDS 16 #1/4 "Metering rod film thickness 36.6μm rod diameter 6.35mm$ 155.00SE
RDS 16# 3/8" Applicator rod 3/8 "SPEC
RDS 16# 3/8" Applicator rod 3/8 "Details
RDS 16# 3/8" Applicator rod 3/8 "Packing list
- SKU
- NB033708
- Production process
- Formed
- WFT
- 36.6µm
- diameter
- 9.52mm
- Total length
- 400mm
- Application width
- 300mm
- material
- stainless steel
16# 3/8"
Applicator rod 3/8 "
Imported from the United States, the production process is formed, the wet film thickness is 36.6μm, the diameter is 9.52mm, the Total length is 400mm, the width of the Spreader is 300mm, and the material is stainless steel.
Product description
RDS linear coating rod is a well-known brand in the coating and ink industry, with a history of hundreds of years. RDS coating rods not only have traditional wire-wound wire rods, but also the current trend of extrusion coating rods, which have a wide range of film thickness from 2 to 95 for optional. In addition, based on years of sales experience, NBCHAO has developed a wet film thickness calculator for users who do not know how to choose a model. RDS 16# 3/8" has a film thickness of 36.6μm and a film width of 30cm.
FAQ
QWhat is the difference between the same 3/8 "diameter round Mayer-Rod and this molding rod? Can it be replaced?
A
The main difference between the Mayer-Rod and the molding rod is the different process of groove formation. The wire rods of the same specification and different processes can be replaced by each other, and the wet film thickness is the same. The difference is because the groove shapes of the two are different (the molding is U-shaped groove, and the winding wire is V-shaped groove). The calculation of the Spreader amount is different, and the relative molded Spreader amount will be more. There is no difference for laboratory use.
QMoulding rod is better for winding or extrusion?
A
In theory, the Moulding effect is the same. The extrusion U-groove is relatively easy to clean, but it requires high asperity on the inner wall of the groove. The winding follows the Mayer principle, and the scraping is smoother. If used for pre-production Measurement, the extrusion Spreader is larger than the winding. The same film thickness was prepared in the laboratory, and the effect was the same.
QCan this cable stick be matched with a Film Applicator?
A
Whether it can be matched with the Film Applicator depends on the film width of the Film Applicator. Most Film Applicator film widths on the market are less than 40cm, and the rod diameter is less than 10mm, so it is suitable. But if the Film Applicator is specially customized, or the width exceeds 40cm, you need to choose a longer rod. For customization, please consult NBchao.
QDo you support customization? Such as wet film thickness and length?
A
Spreader rod length and main rod diameter support customization, but wet film thickness RDS has provided dozens of specifications covering more than 200 microns, and in principle does not accept customization.
