Specifications
| Spreader Accuracy | ±0.001mm或±0.0001mm |
| Spreader thickness range | According to different rod specifications, 1.5μm~ 150μm |
| Standard wire rod | 1 China wire rod + 1 250mm long imported wire rod |
| Coating speed | 5~ 180Mm/s (< 5mm/s can be customized) |
| Coating size | 190*400mm |
| Vacuum Area | 160 * 400Mm (can be customized) |
| Vacuum aperture | Φ1.2mm |
| Vacuum hole spacing | 20*20mm |
| Key control mode | Touch screen control |
| Host Power | 220V 50Hz |
| Dimensions | 690*350*420mm |
| Weight | Net Weight 72KG |
| speed control | Infinitely variable speed |
| Bottom plate material | aluminum alloy |
| Vacuum pump size | 380*180*280mm |
| Customizable function | Jet system device, UV solid-containing device, automatic inking system |
| Optional | Leakage tank, substrate fixture, trimming horizontal height support foot device, Glass plate, Silicone pad and Weight (for applications with uneven substrate thickness of Spreader) |
Packing list
Film Applicator X1, Imported Wire Bar X1, China Wire Bar X1, External Vacuum Pump X1, Product Manual X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/33804/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
