Specifications
| Rated Voltage | AC220V |
| Rated Frequency | 50/60HZ |
| Input Power | 950W |
| output power | 570W |
| Rated torque | 1.95 N.m |
| Duty Cycle | S1 (continuous) |
| Control mode | Combined control knob |
| Speed range | 1000~28000rpm |
| Speed regulation mode | stepless speed regulation |
| Rotation speed display | LED |
| Rotation speed memory function | Yes |
| Approved torque | 190N.cn |
| Work head material | SS 316L stainless steel |
| Environmental temperature | ≤40℃ |
| Allowable Relative Humidity | ≤80% |
| Dimension | 215*310*720mm |
| Machine Weight | 9.0kg |
| Work head specification | 30G |
| Processing Capacity | 100~8000mL |
| Max. Processing Viscosity | 5000cp |
| Rotor maximum linear speed | 22m/s |
| Maximum immersion liquid height | 230mm |
| Work head specification | 30mm |
| Working head length | 295mm |
| Maximum operating temperature | 120℃ |
| Bearing material | PTFE |
| Minimum immersion liquid height | 60mm |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
