Specifications
| Measurement range | 1.0~16.5mm |
| Probe style | PT-102-2000 Standard Probe |
| Probe Frequency | 5.0MHz |
| Speed of sound | 1250~10000m/s |
| Probe diameter | Φ6.3mm |
| Display resolution | 0.01mm |
| Environmental temperature | -10~50℃ |
| Operating Time | 200h |
| Display | LCD display with backlight |
| Host size | 63.5*114.3*31.5mm |
| Weight | 300g |
| Calibration method | Single point, two point calibrated |
| scanning method | 16 points per second measurement, can capture the thinnest point |
| Power Supply | 2 * 5 battery |
| keyboard | 6-Key waterproof, oil-proof keyboard |
Packing list
host X1, PT-102-2000 probe, coupling agent X1, No. 5 battery X2, factory certificate x1, Chinese and English instructions x1, instrument case x1.
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/3385/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
