Specifications
| Measuring range | 50 ~ 1600kpa |
| Accuracy | ≤±0.5% |
| resolution | 0.01kpa |
| deformation error | ≤1mm |
| Concentricity of Upper/Lower plates | ≤0.25mm |
| Film resistance | Resistance range (30 ± 5) kPa at bump height (9 ± 0.2) mm |
| Oil delivery speed | 95±5mL/min |
| Pressure plate diameter | Upper plate diameter: 30.5 ± 0.1mm, lower plate diameter: 33.1 ± 0.1mm |
| Drive structure | All-steel chain drive to prevent compression deviation from detection deviation, improve detection stability and life |
| Deformation monitoring | Chord length 41mm 3D semicircle full window Viewing Window |
| Clamping positioning | 360 ° free orientation positioning test head |
| Measurement head control | Intelligent control pressure relief system |
| positioning area | 65.313cm2 |
| System Power | Fully enclosed solid state Power |
| Display | 3.2In LCD display, real-time display of test data |
| Clamping Force | 100 ~ 1200Kpa |
| unit conversion | Kg / cm2kpalbf / in2 |
| printout | Modular integrated thermal printer |
| Operating Environment | Temperature (20 ± 10) ℃, humidity < 85% |
| Dimensions | 400*400*500mm |
| Weight | 45Kg |
| Air source pressure | Customer-provided (0.4-0.6Mpa) |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. The quality warranty period of the whole machine is one year, and free maintenance is provided for product quality problems during the warranty period (except for man-made damage).
2. Provide lifelong technical services for products outside the warranty period. If repairs are required, only the material fee will be charged, and the maintenance fee will be waived for life.
3. Respond within 3 hours after accepting the service request, and put forward handling opinions and solutions within 24 hours.
4. The returned product will be processed within 5 working days after receipt, and the user will be notified of the processing situation
