Specifications
| Measuring range | 1~48J |
| Measuring range | A file 0~6J, B file 6~ 12, C file 12~ 24, D file 24~ 48J |
| Error of indication | A scale ± 0.05J; B scale ± 0.1J; C scale ± 0.2J; D scale ± 0.5J; (guaranteed within 20% -80% of the upper limit of each measurement) |
| resolution | 0.001J |
| Head pressure | (100 ± 2) kpa |
| Number of swing arm swings | > 120 times (measured by the number of swing arm swings) |
| Pyramid characteristic size | The length of the three bottom edges is 60 * 60 * 60mm, and the height is (25 ± 0.7) mm. |
| Edge fillet radius | R(1.5±0.1)mm |
| Specimen specification | 175×175(mm) |
| Human Machine Interface | 3.2In LCD display, real-time display of test data, can automatically save 20 sets of data |
| printout | Modular integrated thermal printer |
| Dimensions | 900*420*810mm |
| Operating Environment | Temperature (20 ± 10 ℃), humidity < 85%, on horizontal panel |
| Weight | 120kg |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. The quality warranty period of the whole machine is one year, and free maintenance is provided for product quality problems during the warranty period (except for man-made damage).
2. Provide lifelong technical services for products outside the warranty period. If repairs are required, only the material fee will be charged, and the maintenance fee will be waived for life.
3. Respond within 3 hours after accepting the service request, and put forward handling opinions and solutions within 24 hours.
4. The returned product will be processed within 5 working days after receipt, and the user will be notified of the processing situation
