Specifications
| Force range | 2T |
| Measurement size | （1200*1200*1200）mm |
| Force Resolution | 0.01N |
| deformation error | ≤±1mm |
| Force range | 0.4%~100%FS |
| Plate parallelism | ≤1mm |
| Sensors Error Range | ±1% |
| Pressurization speed | 5~ 300mm/min stepless adjustable |
| return speed | 100mm/min |
| compressive strength | 10±3mm/min |
| stacking strength | 5±1mm/min |
| unit switching | N、kgf、Lbf |
| Data analytics | 7In touch screen, with Linear dispersion analysis, thermal printing integrated, with Linear dispersion analysis map printing |
| Test function | Measurement of compressive strength, stacking strength, constant value strength, compressive displacement strength |
| Operating Environment | Temperature (20 ± 10 ℃), humidity < 85% |
| Dimensions | 1700*1200*1900mm |
| Power | 220V、50HZ |
| Plate size | 1200*1200mm |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. The quality warranty period of the whole machine is one year, and free maintenance is provided for product quality problems during the warranty period (except for man-made damage).
2. Provide lifelong technical services for products outside the warranty period. If repairs are required, only the material fee will be charged, and the maintenance fee will be waived for life.
3. Respond within 3 hours after accepting the service request, and put forward handling opinions and solutions within 24 hours.
4. The returned product will be processed within 5 working days after receipt, and the user will be notified of the processing situation
