Specifications
| uniform ink method | Automatic ink leveling (ink leveling time can be adjusted) |
| Rubber roller material | Material can be applied to ordinary offset ink and vegetable oil-based Printing ink |
| Printing Accessories | Printing pressure can be precisely adjusted externally according to the material Film thickness |
| Imprint Paper Specifications | It is best to imprint 0~2.50 mm Film thickness Paper and 1mm Film thickness Plastic film |
| homogenizing speed | Printing speed range: high speed 20 r/min, medium speed 15r/min, low speed 10r/min |
| homogenizing speed | The three-speed direct speed regulation is 650, 800, and 1000 rpm respectively. The speed is adjusted according to the characteristics of Printing ink and Paper, and the speed can be adjusted from 0-1000 rpm. |
| Steel roller speed | Cleaning 100 rpm~ 800 rpm; uniform ink 100 rpm~ 1000 rpm |
| homogenizing speed | Third gear speed regulation 10, 15, 20 rpm, speed regulation, 0-25 rpm |
| Printing roll width | 225mm (maximum development area 225MM × 210MM) |
| Effective area of color bar | 45mm x 225 mm （4条） |
| inverter | Taiwan, China delta delta |
| Dimensions | 690*380*280mm |
| Power | 220V,50Hz |
| power | 400W |
| Operating Environment | Temperature (20 ± 10 ℃), humidity < 85% |
| Weight | About 80KG |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. The quality warranty period of the whole machine is one year, and free maintenance is provided for product quality problems during the warranty period (except for man-made damage).
2. Provide lifelong technical services for products outside the warranty period. If repairs are required, only the material fee will be charged, and the maintenance fee will be waived for life.
3. Respond within 3 hours after accepting the service request, and put forward handling opinions and solutions within 24 hours.
4. The returned product will be processed within 5 working days after receipt, and the user will be notified of the processing situation
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/33882/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
