Specifications
| test channel | 4CH |
| Thermocouple | K type |
| Temperature Measurement Range | -100---500℃ |
| Temperature measurement Accuracy | ±1℃ |
| resolution | 0.1 ℃ (full scale) |
| record data | 120,000 points/channel |
| Sampling interval | 0.05------600 seconds, software settings |
| Total work rate | ≤100mW |
| Operating Voltage | 3.6V (built-in rechargeable battery) |
| Dimensions | 208(L)×75(W)×20(H)mm |
| Protection box size | 252(L)×88(W)×30(H)mm |
| wingspan width | 98----218Mm (std.) |
| Communication port | RS-232 or USB (optional) |
| analysis software | e-DataPro Chinese and English three languages |
Packing list
