Specifications
| Display | 7 inch touch screen |
| heat sealing temperature | RT+~200℃ |
| Temperature control Accuracy | ±0.2℃ |
| Heat sealing time | 0.1~999.9s |
| Heat sealing pressure | 0.05~0.7MPa |
| heat sealing area | Upper heat sealing knife 50 * 10mm (five); lower heat sealing knife 300 * 10mm |
| Heat sealing knife material | aluminum alloy |
| Pneumatic and electrical parts accessories | ordinary accessories |
| Insulation layer | Temperature resistance within 250 ℃ |
| Heating mode | Double heating |
| Heat sealing pressure | 0.5~ 0.7MPa (gas source user-provided) |
| Air source interface | azz8mm polyurethane tube |
| Dimensions | 500*280*480mm |
| Power supply Voltage | AC 220V 50Hz |
| Weight | 80Kg (left and right) |
Packing list
Host X1, power cord X1, manual X1
After-sales instructions
Warranty days: 365 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/33987/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
