Specifications
| Force range | 0~3000N |
| Error of indication | ≤±1% |
| Force range | 0.4%~100%FS |
| Working Travel | 1~80mm |
| Special-shaped compression size | 1~260mm |
| Force Accuracy | +/- within 1% |
| Force resolution | 0.01N |
| Deformation resolution | ≤0.1mm |
| Upper and lower platen parallelism | ≤0.05mm |
| Parallelism self-regulation | 45 °/360 ° 8-stage parallel adjustment |
| Pressurization speed | 12.5±1mm/min |
| Transverse pressure bearing | 71*21mm/10000N |
| Longitudinal pressure bearing | R=20.5mm/2/10000N |
| Axial deviation protection | Brass seat cover |
| System Power | Solid State Power |
| Human Machine Interface | 7Inch touch screen + button test |
| printout | Modular integrated thermal printer |
| Size Weight | 420m×400cm×500mm，38kg |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 540 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
