Specifications
| Specimen size | 38*70mm |
| Actual measurement size | 38*(1~50)mm |
| test spacing | 1mm,5mm,10mm,15mm,20mm,25mm,30mm,40mm,50mm可调 |
| Span Accuracy | ±0.1mm |
| Measurement range | 0~20000mN |
| Sensors | Sensing Accuracy +/- 0.1% |
| Resolution | 0.01mN |
| bending angle | Adjustable from 1 to 92 degrees |
| Multi-angle measurement | Simultaneous setting (1-90 °) of 3 different angles |
| Angular velocity control | 0.5~ 50 °/sec (adjustable) |
| Angle Accuracy | ±0.1° |
| Thickness measurement | （0.01~5.0）mm |
| bending time | （2~50s） |
| Display | 7Inch touchscreen or button test |
| Signal output | Standard computer signal output, link computer (optional) |
| printout | modular integrated thermal printer |
| Dimensions | 320*300*280mm |
| Net Weight | 25kg |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 540 days
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/33994/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
