Specifications
| Sampling size | Ø125mm |
| Blade | Special treatment of mold blades, non-special high-strength materials or man-made damage, no need to replace the blades for 10 years |
| Blade processing technology | Wandu high-precision wire cutting, triple high temperature quenching, triple fine grinding |
| Sampling size error | ±0.2mm |
| Film thickness sampling range | 0.1~1.5mm |
| Blade bite control | Using three-point positioning method, high Accuracy coaxial concentric process |
| Coaxial concentric structure | Three-point guide rail positioning structure, using pure copper wear-resistant copper sleeve |
| Dimensions | 250*280*450mm |
| Weight | Approx. 20 kg |
| Sampling area | Standard test area 100cm2 +/- 0.2cm2 |
| Sampling area | Standard test specimen safety area 122.718 +/- 0.2cm2 |
| Liquid height | 10mm |
| water consumption | Test standard water consumption 100ml +/- 5ml |
| Roller length | Residual moisture removal standard pressure roller 200mm +/- 0.5mm |
| Roller Mass | Standard roller Weight 10kg +/- 0.5kg, foreign standard or special paper can be customized according to requirements |
| Cup material | The whole cup body is made of 304 #stainless steel. |
| Cup lid material | Mg aluminum material, fully enclosed anode hardening process, strong acid and alkali resistance |
| Absorbent paper quantitative | Quantification in the range of 200~250g/m ² |
| Capillary height | Capillary water absorption height greater than 75mm/10min |
| Sealing ring material | Pure silicone sealing ring |
| Cup lid knob cover material | Pure copper material, high-strength wear-resistant process production |
| Cup swirl/spin position | Pure copper material, with wear resistance performance |
| Dimensions | 396*315*300mm |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 540 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/34000/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
