Specifications
| Force range | 10~500N |
| Accuracy grade | Level 1 |
| Force range | 0.4~100%FS |
| Force value Accuracy | ±0.3% |
| Indication of variability | ≤0.3% |
| Elongation Measurement Range | (0~400) mm (under 100mm test length) |
| Test speed Accuracy | (5~100)mm/min±0.2mm/min. |
| Clamp spacing positioning error | ±0.2mm |
| Moving collet reset error | ±0.05mm |
| Force resolution | 0.01N |
| Force unit | N, g, kg, Lb, kpa and other units |
| Displacement resolution | ≤0.1mm |
| Fixture width | 25 (Miscellaneous size can be customized) |
| clip spacing | The test length is (1~ 400) [can be customized] |
| stretching speed | 1~ 500mm/min stepless speed regulation |
| return speed | 150mm/min stepless speed change [ (1~ 550) mm/min adjustable] |
| Drive screw | Adopt Taiwan, China single-column structure precision ball screw |
| Shell material | Made of aluminum alloy |
| motor | Stepper motor, 0~500mm/min stepless speed change |
| Human Machine Interface | 5.0In touch screen control |
| printout | Built-in modular integrated thermal printer |
| Communication interface | Built-in R232 interface, optional connection to computer |
| Size/Weight | 550*550*1100mm、About75kg |
| Power | 220v、50Hz |
| Error of indication | ≤ 0.3% |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 540 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/34001/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
