Specifications
| Force range | 0~30000N |
| Measurement size | （600*400*600）mm |
| test function | Measurement of compressive strength, stacking strength, constant value strength, compression displacement |
| Force Accuracy | +/- 1% or less |
| Sensing deformation error | ≤±1mm |
| Sensors Analytical Accuracy | 0.30% |
| Plate parallelism | ≤1mm |
| Deformation Accuracy | ≤0.1mm |
| Pressurization speed | 5~ 300mm/min stepless adjustable |
| Unit switch | N、kgf、Lbf |
| printout | modular integrated thermal printer |
| Computer control | Computer-specific analysis software, Linear dispersion detail analysis, with dedicated programmable file management analysis report, A4 printing (optional) |
| Safety Devices | 1. Stroke protection: high is the Upper/Lower limit protection switch to prevent exceeding the preset stroke; 2. Force protection: the system can set the force value to prevent exceeding the sensor calibration value; 3. Emergency stop device: This high is equipped with an emergency stop switch, which can handle emergencies; |
| Operating Environment | Temperature (20 +/- 10 ℃), Humidity < 85% |
| Power | 220V/50Hz |
| Power | 400W~2000W |
| Plate size | 600*600mm |
Packing list
host X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 540 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/34011/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
