Specifications
| External input Voltage | AC220V, 50HZ-60HZ |
| Complete-built unit power | 220V/50Hz |
| Printing pressure | Pneumatic pressure, the pressure is adjustable from 0 to 1kpa |
| Pressure regulating switch | Pure bronze, diameter 40mm |
| homogenizing speed | 0-300R/min touch screen adjustable |
| Number of screen plates | Standard one layer version (depth 20um, 25um, 30um, 35um, 40um, 45um) |
| Color bar size | 65 * 45mm/P, a total of 6 sets of Cube angles of 90 degrees |
| Screen plate specifications | ø10 * 200mm roller circumference 345.4mm, roller width 190mm |
| Rubber roller hardness | 60 (adhesive film diameter 220mm) |
| Gray scale | 20%, 30%, 40%, 50%, 60%, 70%, 80%, 90%, 100%. Can be customized upon request |
| Proofing effective area | 110*160mm |
| die | Inner diameter 90mm Outer diameter 95mm |
| Printing size | 190 * 600mm (full circumference) |
| Dimensions | 700*570*570mm |
| Complete-built unit net Weight | 140KG |
Packing list
complete-built unit X1, manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 540 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/34022/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
