Specifications
| Measurement range | 0~1000CSF |
| Analytical Accuracy | 10CSF |
| The Capacity of a round container | 1000ml |
| Volume of conical funnel | 23.5±0.2ml |
| overflow height | 50.8±0.7mm |
| Indoor diameter | 101.6±0.2mm |
| Water filter height | 127.0±0.2mm |
| Valve control | 4.8±0.2mm |
| Screen mesh aperture | Diameter 0.50mm/97H/cm2 |
| cone angle | 29.5°±0.5° |
| Sealing method | Work body sealing + silicone sealing ring structure |
| Sealing ring material | Pure silica gel, acid and alkali resistant. |
| Calibration method | Self-calibrating |
| Cylinder material | 304 #stainless steel |
| Test cup material | 304 #stainless steel |
| Chassis flat bottom bracket material | 304 #stainless steel |
| Standard size | 350*520*1280mm |
| Weight | About 60kg |
Packing list
machine X1, manual X1, certificate X1, warranty card X1
After-sales instructions
Warranty days: 540 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/34026/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
