Specifications
| Standard slurry Capacity | 23L |
| Slurry tank Volume | 47 liters |
| Pulp Pool Warning | With Pulp Tank water level warning, minimum moisture warning 2L |
| Slurry amount | 200G~ 700g absolute dry pulp (standard beating amount: 360g absolute dry pulp, concentration: 1.57%) ideal pulp into the pool size: less than 25 * 25mm |
| Knife roller size | Ø194MM×155MM |
| Knife roller speed | Beating speed (200~900 +/- 10) r/min adjustable |
| Flying blade | Film thickness 4.7mm, 32 pieces |
| Bottom blade | Film thickness 3.2mm, 7 pieces |
| Lever arm load | 54±1N |
| Slurry diversion tank | The plate inner concave slurry diversion structure (both domestically and externally convex) improves the slurry diversion effect. |
| Slurry cover | Short distance 145 degree transparent composite cover, easy to observe the beating fluid in real time, easy to clean the slurry tank and blade cleaning (domestic is 180 degrees inconvenient for manual cleaning). |
| Noise muffler | The slurry outlet is equipped with a noise silencer to reduce the noise during beating. |
| Dimensions | 1240*650*1180mm |
| Power | 750W/380V |
| Net Weight | 200Kg; Gross Weight 280Kg |
Packing list
complete-built unit X1, manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 540 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/34028/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
