Specifications
| Beating method | Double disc sticky beating in the same direction (rubbing type) |
| Beating Pressure | Four-stage strength beating can be achieved, (1.77 +/- 0.1) N/mm blade length; (3.33 +/- 0.1) N/mm blade length; (4.89 +/- 0.1)/mm blade length; (6.45 +/- 0.1)/mm blade length (sold separately). |
| Flying knife lift method | Fully automatic vertical sensing positioning, fully automatic lifting. |
| Flying knife rotor | Outer diameter Φ200mm Height 50mm Knife thickness 5mm |
| Throwing knife material | 304 stainless steel |
| Grinding disc material | 304 stainless steel |
| Flying knife rotor motor | 1.1kW/380v；1400r/m |
| Refining parallelism | 0.01mm |
| Grinding disc clearance distance | The range of 0~25mm can be adjusted. |
| Pulp Tank | Inner diameter Φ250mm, depth 53mm, speed 600r/m |
| Counter display control range | 0-99999999r |
| Linear Speed Difference Between Knife Roller and Slurry Pool | (6.6 +/- 0.2) m/s, (imported models (6.2 +/- 0.2) m/s) |
| Standard refining concentration | Standard concentration 10%. |
| High and low concentration refining dry usage | 5~80g |
| Disc grinding Volume | Volume 600ml. |
| Operating platform structure | It can be adjusted by high and low expansion. |
| Power representation | Real-time display of beating power |
| Power representation | Real-time display of beating power |
| Data Display | 3.2 inch LCD display |
| Effective work display | Effective work can be displayed, KW is indicated. |
| Visual work display | Visible work can be displayed, KW is indicated. |
| Invalid power display | Can display invalid work, KW indicates. |
| Online Voltage display | Voltage can be displayed online in real time, V represents. |
| Online current display | 3 sets of online current display, A represents. |
| Total power consumption display | The Total power consumption can be displayed, KW said. |
| Dimensions | 800*660*1500mm |
Packing list
complete-built unit X1, manual X1, certificate of conformity X1, warranty card X1
After-sales instructions
Warranty days: 540 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
