Specifications
| unit conversion | kpa、psi(Lbs/in2)、kgf/cm2 |
| Resolution | 1kPa |
| Measurement range | 2~80 kg/cm2 (204 Kpa~8160 Kpa) |
| Resolution | 1kPa |
| Error of indication | ±0.5%FS |
| Indication variability | ≤0.5% |
| Oil delivery speed | 170±15mL/min |
| Film resistance | When the protruding height is 10mm, the resistance range is (170-220) kpa; when the protruding height is 18mm, the resistance range is (250-350) kpa. |
| Clamping Force | ≥690Kpa |
| Hydraulic oil | Glycerin 85%, distillation water 15% |
| Clamping Force | ≤1200Kpa |
| Air compressor | Rated pressure (0.6~ 0.7) MPa (optional) |
| Clamp ring diameter | Upper ring: high Voltage type Should be 31.50 +/- 0.5mm; Lower ring: high Voltage type Should be 31.50 +/- 0.5mm |
| Volume | 44×42×56cm |
| Power | AC220V±10% , 50Hz 120W |
| Weight | About 75Kg |
Packing list
Host X1, operation manual X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/34043/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
