Specifications
| pulp pool | Inner diameter φ 250mm, depth 53mm, speed 600r/m |
| Flying knife rotor | Outer diameter φ 200mm Height 50mm Knife thickness 5mm |
| Flying knife rotor motor | 1.1kW/380v；1400r/m |
| Buckle clearance adjustment distance | 0~25mm |
| slurry pool motor | 370W/380v； 1400n/m |
| Counter display control range | 0-999999 rpm |
| Linear Speed Difference between Knife Roller and Pulp Pool | （6.0±0.2）m/s |
| Deducting pulp concentration | 5~ 20%; Absolute dry pulp 5~ 30g |
| Beating Pressure | (3.33 +/- 0.1) N/mm blade length; (1.77 +/- 0.1) N/mm blade length; (4.89 +/- 0.1)/mm blade length |
| Dimensions | 860*450*1100mm |
| net Weight | 251Kg |
Packing list
Host X1, operation manual X1, warranty card X1
After-sales instructions
Warranty days: 365 days
1. For product quality problems caused by non-human products of instruments and equipment, the manufacturer will provide free warranty services during the warranty period;
2. There is no warranty period for fragile and consumable parts, and if you find product quality problems after receiving the goods, please apply for return and exchange within 7 days, and you will not wait for the overdue ones;
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/34044/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
