Specifications
| Measurement range | 1~500mN·m |
| Indication Accuracy | +/- 2% (10% to 90% of the upper limit of each measurement) |
| Indication Repeatability Error | ≤ 2% (within 10% to 90% of the upper limit of each measurement) |
| swing arm length | 100mm |
| Load arm length | 50mm±0.1mm |
| Test speed | 200mm/min |
| bending angle | ±7.5°/±15° |
| Specimen size | 70*38mm |
| Dimensions | 270*165*355mm |
| Mass | About 19kg |
Packing list
After-sales instructions
None
[Note] For after-sales services outside the Chinese mainland, if the instrument requires repair, the shipping and possible associated taxes shall be borne by the sender. Generation address of the manual: http://en.nbchao.com/p/34071/Specification.html , which is only used by users who purchase commodities from the NBCHAO.
