Specifications
| Shaker Table Size | 500X500mm, 600 * 700mm, 1000 * 1000mm or other specifications; |
| vibration direction | Vertical + horizontal or vertical |
| Maximum test Weight | 100KG |
| Frequency adjustment range | 1~600HZ |
| Sweep range | 1-600HZ; (seconds can be set at any time within 1 year) up to 5000HZ, which can be explained when ordering. |
| Amplitude | 0—5mm; |
| Maximum Acceleration | 20g; |
| time control | Within a year/in seconds; |
| vibration waveform | Sine wave, half sine wave; |
| Vibrator Power | 2.2KW; |
| Power | 220V±10% |
| Maximum current | 5A; |
| Precision | Frequency can be displayed to 0.01HZ, precision 0.1HZ |
| Shaker Table Size | 50X50X16cm. |
